CPU架构支持 |
Intel LGA2011/1366/1150/1155/1156 |
|
|
AMD FM2+/FM2/FM1/AM3+/AM3/AM2+/AM2 |
||
|
解热功率 |
150W |
|
|
尺寸 |
100x122x125mm (L×W×H) |
|
|
材质 |
Copper Base+4×Ф6mm Copper Heatpipe+Aluminum Fin |
|
|
重量 |
550g(with fan) |
|
|
|
Fan 1 |
Fan 2 (in the middle) |
|
风扇尺寸 |
92×92×25mm |
92×92×25mm |
|
风扇转速 |
600-2200RPM(PWM) |
600-2200RPM(PWM) |
|
最大风量 |
38.5CFM |
38.5CFM |
|
最大风压 |
1.92mmH2O |
1.94mmH2O |
|
噪音 |
14-23dB(A) |
14-23dB(A) |
|
额定电压 |
12VDC |
12VDC |
|
操作电压 |
10.8～13.2VDC |
10.8～13.2VDC |
|
启动电压 |
7VDC |
7VDC |
|
额定电流 |
0.16A |
0.16A |
|
输入功率 |
1.92W |
1.92W |
|
轴承形式 |
Hydraulic Bearing |
Hydraulic Bearing |
